Computers for video measurement systems in lab and production

Order number: NUC-PC
€1.200,00 *

* Price without VAT - plus Shipping costs

The compact NUC-Intel® computer for laboratory and production ready configured with Metric measurement software and USB drivers for camera and controllers

On backorder (Delivery time: 6 Wochen)
We offer you the perfect and extremely small INTEL NUC PC as an option for your measuring system. Upon delivery, the Metric measurement software and all necessary drivers are already installed. If the PC is delivered with the video measuring system, the system is already calibrated and ready for immediate use. Below are the technical specifications of the INTEL NUC PC:

- KCS Business Intel NUC PC Core i7
- 1x Intel Core i7-1071OU, 6x 1.1 to 4.7 GHz (Comet Lake), full-size, black/silver
- 2x Samsung - 8 GB DDR4-2666 (1x8GB) (SO-DIMM)
- 1x Intel Ultra HD Graphics, DirectX12, FullHD (up to 4K)
- 1x Samsung 850 EVO - SSD 250 GB, MZ-N6E250BW, SATA-600
- 1x Notebook Wireless LAN max 2400 MBit (Ax) + Bluetooth 4.0 (integrated)
- 1x Windows 10 Pro, 64-bit (SB) (or Windows 11)
- 1x Microsoft Office 2019 Home & Business, PKC (licence only)
- 1x HDMI to DisplayPort cable 2m
- Available connections: Graphics: 2x HDMI 2.0
- Picture output via HDMI 2.0a: max. 4,096 x 2,160 @ 60 Hz
- HDMI 2.0a: max. 4,096 x 2,160 @ 60 Hz
- 2x HDMI 2.0
- USB: 1x USB3.0, 1x USB-C 3.1 (rear) 2x USB3.0 (front)
- LAN: Intel PRO Gigabit network card
- WLAN: Intel Dual Band Wireless-AC 8265, 802.11abgn + Bluetooth + Intel Wireless Display
- Accessories: Logitech Wireless Combo MK520 - keyboard, mouse connection: wireless,
- Accessories: HDMI to DisplayPort cable 2m (supplied by KITOTEC GmbH)
- Samsung UHD Monitor U28E590D, in 28" with resolution 3840 x 2160

The Windows 10 or Windows 11 systems we deliver are completely cleaned (no games, unnecessary apps ect.) as well as provided with the latest updates. Drivers for interface and Metric measurement software are already installed. Video microscopes included in the delivery are already calibrated.

Due to technical development or availability of components, the delivery in details and the pictures presented here may differ from the actually delivered PC. Technical changes are therefore reserved in principle. Technical data of the monitor (as of September 2022):


Screen size (inch) 28.0
Screen size (cm) 70.8
Screen size (Class) 28
Flat / Curved: Flat
Active display area (H x V) (mm) 620.928(H) * 341.28(V)
Screen Curvature N/A
Aspect Ratio 16:9
Panel Type IPS
Brightness (Normal) 300 cd/㎡
Brightness (Min.) 250 cd/㎡
Contrast Ratio Static 1,000:1(Typ.)
Dynamic Contrast Ratio Mega ∞ DCR
HDR(High Dynamic Range) HDR10
Screen Resolution 3,840 x 2,160
Response Time 4(GTG)
Viewing Angle (H / V) 178°/178°
Color Support Max 1B
Color Gamut (DCI Coverage) 0.9
Refresh Rate Max 60Hz

Interface

Wireless display: No
D-Sub: No
DVI: No
Dual Link DVI: No
Display Port: 1 EA
Display Port Version: 1.2
Display Port Out: No
Display Port Out Version: No
Mini Display Port: No
HDMI: 2 EA
HDMI Version: 2
Audio Input: No
Headphones: Yes
USB Ports: No
USB Hub Version: No
USB-C: No

General Features:

Samsung MagicBright: Yes
Samsung MagicUpscale: Yes
Eco Saving Plus: Yes
Eye Saver Mode: Yes
Flicker Free: Yes
Picture-in-Picture: Yes
Picture-By-Picture: Yes
Game Mode: Yes
Picture Size: Yes
Easy Setting Box: Yes
Windows Certification: Windows 10
FreeSync: Yes
Off Timer Plus: Yes

Audio

Speakers: No
USB Sound Bar (Ready): No

Operating conditions

Temperature 10~40 ℃
Humidity 10~80,non-condensing

Calibration

Factory calibrated: Yes

Design

Color DARK BLUE GRAY
Stand SIMPLE
Tilt -2.0˚(±2.0˚) ~ 15.0˚(±2.0˚)
Wall mount 75.0 x 75.0

Eco-mode

Energy efficiency class G
Operating current
Power supply AC 100~240V
Power consumption (max.) 48 W
Power consumption (type) 32.0 W
Power consumption (DPMS) ≤0.5 W
Power consumption (Off mode) ≤0.3 W
Power consumption (annual) 47 kWh/year
Type External Adaptor

Dimensions

Overall dimensions with base (W x H x D) 638.8 x 479.3 x 250.5 mm
Overall dimensions without base (W x H x D) 638.8 x 374.0 x 64.0 mm
Packing dimensions (W x H x D) 732.0 x 176.0 x 465.0 mm

Weight

Weight with base (kg) 5.8 kg
Weight without foot (kg) 5.0 kg
Weight with packaging 7.8 kg

Scope of delivery

Power cable length 1.5 m
D-Sub cable: No
DVI cable: No
HDMI cable: Yes
HDMI to DVI cable: No
DP Cable: No
USB Type-C Cable: No
Thunderbolt 3 Cable: No
Mini Display Gender: No
Audio Cable: No
USB 2.0 Cable: No
USB 3.0 Cable: No
Remote Controller: No
